LSC | 1-phase / 50Hz

Original residue dewatering pump capable of pumping down to floor level. Even the smallest puddle can be pumped dry. Ideal for complete drainage of flat surfaces where a sump is not available: rooftops, parking lots, garages, roadways, pools,...

LSC | 1-phase / 50Hz
ModelColour code curveBore mmMotor output kWRated current AHead max. mCapacity max. l/minDry weight kg w/o cableMax. solid handling ø mmPressure resistance max. mCable length m
LSC1.4S 25 0,48 2,9 11,0 170 12,0 6 10 10
LSCE1.4S   25 0,48 2,9 11,0 170 12,6 6 10 10
LSC2.75S 50 0,75 4,5 15,0 228 15,2 6 10 10
ø Discharge bore mm 25, 50
Pumping Fluid Type of Fluid Cleaning water, Water on floor, Puddles
Temperature 0-40°C
Pump Compo- nents Impeller Semi-Vortex impeller
Shaft Seal Double mechanical seal
Bearings Shielded ball bearings
Material Impeller Urethane rubber
Casing Ethylene propylene rubber
Suction Plate Steelplate+Urethane rubber
Shaft Seal Silicon carbide in oil bath
Motor Lubrication Turbine oil (ISO VG32)
Phase / Voltage Single phase 230V / 110V / 50Hz
Type, Poles Induction motor, 2 poles, IP68
Motor Protector (built-in) Miniature protector
Insulation Insulation class E
Material Casing Aluminium die casting
Shaft Stainless steel EN-X6Cr13
Cable Rubber, 10m H07RN8-F
Discharge Connection Hose coupling

Dimensions in mm:

  • LSCE1.4S
  • LSC1.4S
  • LSC2.75S

W1: lowest running water level

In the event of abrasive and corrosive utilization, stronger wear and tear will take place naturally in certain components. In this regard, please pay attention to our website www.tsurumi.eu/english/applications.htm.
